Power +
Rating
(KVA)
PowerOutput
(HP)
FuelConsumption
(Litre/Hr)
Gensets
Dimension
(LxWxH)mm
Gensets
Weight(kg)
FuelTank
capacity
75% 100%
5 10 1.62 2 1417x820x1300 630 50
7.5 10 1.62 2 1800x900x1300 650 50
10 18 2.2 2.5 1800x900x1300 650 50
12.5 18 2.6 3 1767x820x1328 690 50
15 25 3 3.4 1800x900x1300 690 50
20 33 3.2 4.5 1800x900x1300 800 65
22.5 33 3.5 4.7 2000x950x1285 840 65
25 38 4.5 5.8 2000x950x1285 840 65
30 38 5.2 6.8 2000x950x1285 950 100
35 44 5.2 6.8 2000x950x1285 950 100
40 57 7 8.6 2500x1030x1330 1280 150
45 57 7 8.6 2500x1030x1330 1280 150
50 72 8.9 11.2 2500x1030x1330 1290 230
62.5 90 10.2 13.5 2900x1110x1600 1700 230
82.5 102 11.5 15.2 3200x1200x1600 1750 300
100 156 15.5 18.5 3200x1200x1600 1900 300
Rating
(KVA)
Power
Output(HP)
FuelConsumption
(Litre/Hr)
Gensets
Dimension
(LxWxH)mm
Gensets
Weight(kg)
FuelTank
capacity
75% 100%
160 199 95 110 4000x3110x1600 2800 300
180 223 28 37 3790x1300x1800 2850 400
200 248 31 36 4300x1400x1800 2900 400
250 310 40 52 4600x1500x2025 3800 400
320 390 50 65 4800x1700x2025 4000 400
380 492 64 88 5950x2000x2350 6000 400
400 492 64 88 5950x2000x2350 6000 Custom
450 607 77 99 5950x2000x2350 6500 Custom
500 607 77 99 5950x2000x2350 6500 Custom
625 901 120 150 6800X2300X2713 8550 Custom
750 901 120 150 6800X2300X2713 8550 Custom
910 1086 160 190 8000X2300X2713 14000 Custom
1010 1210 150 190 8000X2300X2713 14000 Custom
Technical Specification :
Powerfactor 0.8
Custom
NoiseLevel CPCBsecondDBA<75 Refillablefueltanksuggested
SpecificGravity0.845 Tolerancefactor+/-5%
